Technical & Performance guides
How tractor lighting systems work. From wiring and voltage to beam angles and lumens, these guides explain the setup behind reliable farm lighting.
24 guides
- Technical & Performance
Do LED Lights Interfere with GPS and Auto-Steer Systems
LED lights interfere with tractor GPS and auto-steer when the LED driver emits radio frequency noise on the same bands as the...
- Technical & Performance
Power Draw Comparison: LED, Halogen, and Xenon on 12V and 24V Systems
Vehicle work-light power draw is the current in amperes that a lamp pulls from the tractor electrical system at its rated voltage,...
- Technical & Performance
How to Wire Work Lights: 12V and 24V with a Relay and Switch
To wire work lights on a 12V or 24V tractor, run a fused feed from the battery positive to pin 30 of...
- Technical & Performance
What IP Rating Do You Need for Agricultural LED Lights
The IP rating on an agricultural LED light tells you how much dust and water the housing can keep out. Farm vehicles...
- Technical & Performance
Halogen Work Lights: When Old Technology Still Makes Sense
A halogen work light is a tungsten-filament lamp filled with halogen gas, fitted to tractors, trailers and plant machinery to illuminate work...
- Technical & Performance
Fuses and Circuit Protection for Vehicle Lighting
A vehicle lighting fuse is a sacrificial component sized to interrupt the circuit when current exceeds a safe level. The fuse protects...
- Technical & Performance
EMC Compliance: Why It Matters for LED Lights on Modern Tractors
EMC compliance is the ability of an electrical product to operate without generating electromagnetic noise that disturbs other equipment, and to keep...
- Technical & Performance
Beacon Not Working? How to Fix a Beacon That Won’t Flash
When a beacon is not working, the cause is usually in the supply rather than the beacon itself: a blown fuse, a...
- Technical & Performance
7-Pin Trailer Plug Wiring: 12N and 12S Diagrams and Colours
A 7-pin 12N trailer plug (ISO 1724) is wired: pin 1 yellow, left indicator; pin 2 blue, rear fog lamp; pin 3...
- Technical & Performance
Adding Extra Lights to Your Tractor Without Overloading the Circuit
Adding extra lights to a tractor without overloading the circuit needs three calculations and one design choice. The first calculation is the...
- Technical & Performance
12V vs 24V Work Lights: How to Tell What Your Tractor Runs
Almost every tractor runs a 12V electrical system, including large modern machines; 24V is mainly found on HGVs, buses, military vehicles and...
- Technical & Performance
13-Pin Trailer Plug Wiring: Socket Diagram, Colours and Adapters
A 13-pin trailer plug (ISO 11446) carries the 7 lighting circuits of a 12N plug on pins 1 to 7, with the...
